Harley-Davidson STREET

harley-davidson street

H-D Street for sale

Harley Davidson Street 500 reviews

Harley-Davidson Street 500 specs

DIMENSIONS

  • LENGTH 2,215 mm
  • SEAT HEIGHT, UNLADEN 720 mm
  • GROUND CLEARANCE 145 mm
  • RAKE 32
  • TRAIL 115 mm
  • WHEELBASE 1,520 mm
  • TYRES, FRONT SPECIFICATION 100/80-17
  • TYRES, REAR SPECIFICATION 140/75 R15
  • FUEL CAPACITY 13.1 l
  • OIL CAPACITY (W/FILTER) 3.1 l
  • WEIGHT, AS SHIPPED 223 kg
  • WEIGHT, IN RUNNING ORDER 233 kg

ENGINE

  • ENGINE Liquid-cooled, Revolution®X V-Twin
  • BORE 69 mm
  • STROKE 66 mm
  • DISPLACEMENT 494 cc
  • COMPRESSION RATIO 10.5:1
  • FUEL SYSTEM Electronic Sequential Port Fuel Injection (ESPFI)
  • EXHAUST Black two into one

PERFORMANCE

  • ENGINE TORQUE TESTING METHOD EC 134/2014
  • ENGINE TORQUE 40 Nm
  • ENGINE TORQUE (RPM) 3,750
  • LEAN ANGLE, RIGHT (DEG.) 28.5
  • LEAN ANGLE, LEFT (DEG.) 28.5

DRIVE TRAIN

  • PRIMARY DRIVE Gear, 36/68 ratio
  • GEAR RATIOS (OVERALL) 1ST 14.272
  • GEAR RATIOS (OVERALL) 2ND 10.074
  • GEAR RATIOS (OVERALL) 3RD 7.446
  • GEAR RATIOS (OVERALL) 4TH 6.006
  • GEAR RATIOS (OVERALL) 5TH 5.037
  • GEAR RATIOS (OVERALL) 6TH 4.533

CHASSIS

  • WHEELS, FRONT TYPE Black, 7-spoke Cast Aluminium
  • WHEELS, REAR TYPE Black, 7-spoke Cast Aluminium
  • BRAKES, CALIPER TYPE 2-piston floated front and rear

ELECTRIC

  • LIGHTS (AS PER COUNTRY REGULATION), INDICATOR LAMPS High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
  • GAUGES 3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap

Harley-Davidson Street 750 reviews

Harley-Davidson Street 750 specs

DIMENSIONS

  • LENGTH 87.2 in.
  • SEAT HEIGHT, LADEN 7 25.7 in.
  • GROUND CLEARANCE 5.7 in.
  • RAKE 32
  • TRAIL 4.5 in.
  • WHEELBASE 59.8 in.
  • TIRES, FRONT SPECIFICATION 100/80-17
  • TIRES, REAR SPECIFICATION 140/75 R15
  • FUEL CAPACITY 3.5 gal.
  • OIL CAPACITY (W/FILTER) 3.3 qt.
  • WEIGHT, AS SHIPPED 492 lb.
  • WEIGHT, IN RUNNING ORDER 514 lb.

ENGINE

  • ENGINE 1 Liquid-cooled, Revolution®X V-Twin
  • BORE 3.35 in.
  • STROKE 2.6 in.
  • DISPLACEMENT 46 cu in
  • COMPRESSION RATIO 11:01
  • FUEL SYSTEM 3 Mikuni Single Port Fuel Injection, 38 mm bore
  • EXHAUST Black two into one

PERFORMANCE

  • ENGINE TORQUE TESTING METHOD J1349
  • ENGINE TORQUE 2 43.5 ft-lb
  • ENGINE TORQUE (RPM) 4000
  • LEAN ANGLE, RIGHT (DEG.) 28.5
  • LEAN ANGLE, LEFT (DEG.) 28.5
  • FUEL ECONOMY TESTING METHOD Estimated City/Hwy
  • FUEL ECONOMY 55 mpg

DRIVE TRAIN

  • PRIMARY DRIVE Gear, 36/68 ratio
  • GEAR RATIOS (OVERALL) 1ST 14.272
  • GEAR RATIOS (OVERALL) 2ND 10.074
  • GEAR RATIOS (OVERALL) 3RD 7.446
  • GEAR RATIOS (OVERALL) 4TH 6.006
  • GEAR RATIOS (OVERALL) 5TH 5.037
  • GEAR RATIOS (OVERALL) 6TH 4.533

CHASSIS

  • WHEELS, FRONT TYPE Black, 7-Spoke Cast Aluminum with Machined Rim Highlights
  • WHEELS, REAR TYPE Black, 7-Spoke Cast Aluminum with Machined Rim Highlights
  • BRAKES, CALIPER TYPE 2-piston floated front and rear

ELECTRIC

  • LIGHTS (AS PER COUNTRY REGULATION), INDICATOR LAMPS High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
  • GAUGES 3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap

Harley-Davidson Street Rod reviews

Harley-Davidson Street Rod specs

DIMENSIONS

  • LENGTH 83.9 in.
  • SEAT HEIGHT, LADEN 7 29.8 in.
  • GROUND CLEARANCE 8.1 in.
  • RAKE 27
  • TRAIL 3.9 in.
  • WHEELBASE 59.4 in.
  • TIRES, FRONT SPECIFICATION 120/70 R17 V
  • TIRES, REAR SPECIFICATION 160/60 R17 V
  • FUEL CAPACITY 3.5 gal.
  • OIL CAPACITY (W/FILTER) 3.3 qt.
  • WEIGHT, AS SHIPPED 505 lb.
  • WEIGHT, IN RUNNING ORDER 525 lb.

ENGINE

  • ENGINE High Output Revolution®X V-Twin
  • BORE 3.4 in.
  • STROKE 2.6 in.
  • DISPLACEMENT 46 cu in
  • COMPRESSION RATIO 12.0:1
  • FUEL SYSTEM Mikuni Twin Port Fuel Injection, 42 mm bore
  • EXHAUST Black two-into-one exhaust

PERFORMANCE

  • ENGINE TORQUE TESTING METHOD J1349
  • ENGINE TORQUE 47 ft-lb
  • ENGINE TORQUE (RPM) 4000
  • LEAN ANGLE, RIGHT (DEG.) 37.3
  • LEAN ANGLE, LEFT (DEG.) 40.2
  • FUEL ECONOMY TESTING METHOD Estimated City/Hwy
  • FUEL ECONOMY 54 mpg

DRIVE TRAIN

  • PRIMARY DRIVE Gear, 36/68 ratio
  • GEAR RATIOS (OVERALL) 1ST 14.272
  • GEAR RATIOS (OVERALL) 2ND 10.074
  • GEAR RATIOS (OVERALL) 3RD 7.446
  • GEAR RATIOS (OVERALL) 4TH 6.006
  • GEAR RATIOS (OVERALL) 5TH 5.037
  • GEAR RATIOS (OVERALL) 6TH 4.533

CHASSIS

  • WHEELS, FRONT TYPE Black, 7-Split Open Spoke Cast Aluminum
  • WHEELS, REAR TYPE Black, 7-Split Open Spoke Cast Aluminum
  • BRAKES, CALIPER TYPE 2-piston floated front and rear

ELECTRIC

  • LIGHTS (AS PER COUNTRY REGULATION), INDICATOR LAMPS High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
  • GAUGES 3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap
