Harley-Davidson FXDR ‘LDA 86’ by Thunderbike

Harley-Davidson FXDR ‘LDA 86’ by Thunderbike

Harley-Davidson FXDR ‘LDA 86’ by Thunderbike



[email protected]

Geolocation Hamminkeln




“Green Hell” it’s called, like the legendary Nordschleife, the oldest part of the Nürburgring, where Lance feels at home. The abbreviation “LDA 86” for his name and year of manufacture can be found on all the vehicles in Lance’s fleet. We have engraved it as a special design on various lids for him.

What makes this bike, however, are our matched components: Single-sided swingarm, big wheels, lowered front and rear, rear fender with lights, side license plate, nose spoiler and various black covers. And yes, of course we beefed up the powerful Milwaukee-Eight 114 engine with the torque kit (Screamin’ Eagle Stage II) and the big air cleaner and tuned it with DON Performance.

H-D FXDR parts

  • Thunderbike Single-Side Swingarm Kit 21” Alu
  • Thunderbike Pulley Vegas
  • Thunderbike Slamtail Suspension Kit
  • Thunderbike Vegas Race wheel
  • Thunderbike Triple Tree GT 23”
  • Thunderbike Fork Modification Lowering Destruction
  • Thunderbike Handlebar Clip-On Lowering black
  • Thunderbike Grip-Set Base Alu
  • Thunderbike Turn Signal Bracket front M8 black
  • Thunderbike Toppers Base
  • Motogadget mo.Blaze Pin Turn Signal Set
  • Thunderbike Front fender GT 23” GRP
  • Thunderbike Rear Fender GP-Style 260 mm
  • Thunderbike License Plate Frame Inside Plate
  • Thunderbike License Plate Lighting
  • Motogadget mo.View Mirror Sport black
  • Thunderbike Airbox Kit Oval
  • Harley-Davidson Screamin’ Eagle 10mm Phat Spark Plug Wires black
  • Harley-Davidson Screamin’ Eagle Stage II Torque Kit
  • Thunderbike Chin Fairing GP Short GRP
  • Thunderbike Timer Cover Drilled
  • Thunderbike Brake Disc Vegas Floated 340mm
  • Thunderbike Forward Controls Grand Prix black
  • Thunderbike Seat Plate
  • Thunderbike Belt 1” heavy duty
  • Thunderbike EFI-Cover black wrinkle
  • Thunderbike Derby Cover Drilled contrast cut
  • Thunderbike Front Axle Cover-Set black matte
  • Thunderbike Axle Cover Swingarm left
  • Metzeler Cruisetec Rear Tire 260/35VR21 83V
  • Metzeler ME888F Front Tire 130/60B23 M/C TL 65H

H-D FXDR specs

Part of the Softail category, the 2018 Harley-Davidson FXDR 114 has been designed using plenty of alloy and composite components to reduce the bike’s weight, including an all-new aluminum swingarm and subframe.

Engine Specs

Type Milwaukee-Eight 114
Displacement 1868 Cm3
Bore X Stroke 4.0X4.5 In Or 102 Mm
Compression Ratio 10.5:1
Horsepower -/- Kw(Hp)/Rpm
Torque 119/3500 Lb-Ft/Rpm Or 161/3500 Nm/Rpm
Fuel System Electronic Sequential Port Fuel Injection (Espfi)

Transmission Specs

Gearbox 6-Speed Cruise Drive
Clutch Wet Multi-Plate
Primary Drive
Final Drive Chain

Chassis Specs

Frame Steel Tubular Frame
Front Suspension Single Cartridge 43 Mm Inverted With Aluminum Fork Triple Clamps; Triple Rate Spring
Rear Suspension Hidden, Free Piston, Coil-Over Monoshock; 43 Mm Stroke; Toolless Hydraulic Preload Adjustment
Front Brake Double Discs 300 Mm
Rear Brake Single Disc 292 Mm

Dimension Specs

Overall Length 95.1 In Or 2416 Mm
Overall Width 36.6 In Or 930 Mmseat Height28.5 In Or 724 Mm
Weelbase 68.4 In Or 1737 Mm
Ground Clearance 5.3 In Or 135 Mm
Weight 668 Lbs Or 303 Kg
Fuel Capacity 4.4 Gallons Or 16.7 L

Tyres Specs

Front 120/70Zr-19 60W
Rear 240/40R-18 79V
