POWERTRAIN | 100% CNC machined aerospace grade 6061-T6 billet aluminum Confederate design patented* unitized proprietary 56° 132 CI squared bore and stroke 160+ horsepower, air/oil cooled, big block V-twin featuring 200 ft. lbs. of torque through drag race proven clutch and 5-speed overdrive, straight cut transmission.
CHASSIS | 100% CNC machined aerospace grade 6061-T6 billet aluminum Confederate design patented proprietary drag racing derived aerospace inspired fuselage, bulkhead, monocoque locating unitized powertrain.
SPECIFICATIONS | Wheelbase: 62.5″ / Fuel Capacity: 3.75 Gallons / Oil Capacity: 6 Quarts / Weight: 500 Pounds
SUSPENSION: Confederate Proprietary | Front: Double Wishbone Girder Link W/ Coilover & Integrated Reservoir; Multi-Adjustable High & Low Speed Compression & Rebound dampening. Rear: Multi-Link Coilover W/ Remote Reservoir; Multi-Adjustable High & Low Speed Compression & Rebound dampening.
TIRES | Front: 120/70-ZR19 Pirelli Rear: 240/45-ZR17 Pirelli
WHEELS: Confederate Proprietary | Front: 19″ x 3.5″ 5-Spoke Carbon Fiber Rear: 17″ x 8.5″ Solid Disc Carbon Fiber
* Engineering patent 5,857,538 granted for superior, class leading torsion and bend rigidity.
