Builder BLACK BOBBER
Contact [email protected]
Country Switzerland
Model Indian Scout
Style Bobber
BOBBER STYLE VIDEOS
Engine and transmission
- Displacement: 1133.0 ccm (69.14 cubic inches)
- Engine type: V2, four-stroke
- Engine details: Liquid Cooled 60 degree V-Twin
- Power: 100.0 HP (73.0 kW))
- Torque: 97.6 Nm (10.0 kgf-m or 72.0 ft.lbs) @ 6000 RPM
- Compression: 10.7:1
- Bore x stroke: 99.0 x 73.6 mm (3.9 x 2.9 inches)
- Fuel system: Injection. Closed Loop Fuel Injection, 60 mm Bore
- Cooling system: Liquid
- Gearbox: 6-speed
- Transmission type,
- final drive: Belt
- Clutch: Wet, Multi-Plate. Gear Drive Wet Clutch.
- Exhaust system: Split dual exhaust with crossover
Chassis, suspension, brakes and wheels
- Rake (fork angle): 29.0°
- Trail: 120 mm (4.7 inches)
- Front suspension: Telescopic fork
- Front wheel travel: 120 mm (4.7 inches)
- Rear suspension: Dual shock
- Rear wheel travel: 76 mm (3.0 inches)
- Front tire: 130/90-16
- Rear tire: 150/80-16
- Front brakes: Single disc. Optional ABS. Two-piston calipers.
- Diameter: 298 mm (11.7 inches)
- Rear brakes: Single disc. Optional ABS. Single-piston caliper.
- Diameter: 298 mm (11.7 inches)
- Wheels: Contrast Cut wheels. Pirelli Night Dragon tires.
- Seat: 2-Up Sport Seat
Measures and capacities
- Dry weight: 246.0 kg (542.3 pounds)
- Weight incl. oil, gas, etc: 254.0 kg (560.0 pounds)
- Power/weight ratio: 0.4065 HP/kg
- Seat height: 656 mm (25.8 inches) If adjustable, lowest setting.
- Overall height: 1068 mm (42.0 inches)
- Overall length: 2324 mm (91.5 inches)
- Overall width: 916 mm (36.1 inches)
- Ground clearance: 145 mm (5.7 inches)
- Wheelbase: 1576 mm (62.0 inches)
- Fuel capacity: 12.50 litres (3.30 US gallons)
