Builder DUCATI HAMBURG
Contact [email protected]
Country Germany
Model Ducati XDiavel
Country Racer
Ducati XDiavel specs
Engine Specs
Type Liquid-Cooled, Four-Stroke, Testastretta Dvt L-Twin, Demodromic 4 Valves Per Cylinder
Displacement 1262 Cm3
Bore X Stroke 4.2X2.8 In Or 107 Mm
Compression Ratio 13:1
Horsepower 156/9500 Kw(Hp)/Rpm
Torque 95/5000 Lb-Ft/Rpm Or 129/5000 Nm/Rpm
Fuel System Efi
Transmission Specs
Gearbox 6-Speed, Manual
Clutch Wet, Multiplate, Sipper-Type
Primary Drive Straight Cut Gears
Final Drive Belt
Chassis Specs
Frame Tubular Steel Trellis
Front Suspension 50Mm Adjustable Upside-Down Fork
Rear Suspension Adjustable Monoshock
Front Brake Dual 320Mm Discs, 4-Piston Calipers, Brembo Monobloc, Cornering Abs
Rear Brake Single 265Mm Disc, 2-Piston Caliper, Cornering Abs
Dimension Specs
Overall Length 90.9 In Or 2309 Mm
Overall Width 39.8 In Or 1011 Mm
Seat Height 29.7 In Or 754 Mm
Weelbase 63.6 In Or 1615 Mm
Ground Clearance –
Weight 485 Lbs Or 220 Kg
Fuel Capacity 4.8 Gallons Or 18.2 L
Tyres Specs
Front 120/70 Zr17
Rear 240/45 Zr17
