Model Ducati XDiavel
Style Racer
Engine
- Type 90º V-twin, four valves per cylinder, liquid cooled
- Displacement 1,262cc
- Compression 13:01
- Electrical start
- Bore x Stroke 106mm x 71.5mm
- Power 159 CV at 9,500 r.p.m.
- Engine torque 129 Nm at 7,500 r.p.m.
- Electronic start
- Feeding Electronic injection
- Multi-disc clutch in oil bath with anti-rebound system
- Gearbox Six speed
Cycle part
- Steel tubular chassis
- Front suspension Öhlins 48 mm diameter inverted fork, adjustable and with TiN treatment
- Rear suspension Adjustable Öhlins monoshock
- Front brake Dual 320mm discs with Brembo M50 radial mount monobloc calipers
- Rear brake 265mm disc with Brembo two-piston caliper
- Front tire Pirelli Diablo Rosso III 120/70 ZR17
- Pirelli Diablo Rosso III 240/45 ZR17 rear wheel
Dimensions
- Wheelbase 1,600mm
- Length N/A
- Width N/A
- Seat height 780 mm
- pitch 27th
- advance 120mm
- Weight in running order 246 kg
- 17 liter tank
