H-D FAT BOY

H-D Fat Boy Specs

Engine specs

TYPE Air-cooled, Screamin’ Eagle Twin Cam 110B
DISPLACEMENT 1801 cm3
BORE X STROKE 4.0×4.4 in OR 102 mm
COMPRESSION RATIO 9.2:1
HORSEPOWER -/- KW(hp)/RPM
TORQUE 108/4000 lb-ft/RPM OR 146/4000 Nm/RPM
FUEL SYSTEM Electronic Sequential Port Fuel Injection (ESPFI)

Transmission specs

GEARBOX 6-Speed
CLUTCH Wet Multi-disc
PRIMARY DRIVE Gears
FINAL DRIVE Chain

Chassis specs

FRAME-FRONT SUSPENSION Telescopic fork
REAR SUSPENSION Dual shock adjustable
FRONT BRAKE 4-piston fixed
REAR BRAKE 2-piston floated caliper

Dimension specs

OVERALL LENGTH 93.9 in OR 2385 mm
OVERALL WIDTH-SEAT HEIGHT 26.4 in OR 671 mm
WEELBASE 64.2 in OR 1631 mm
GROUND CLEARANCE 4.9 in OR 124 mm
WEIGHT 734 lbs OR 333 kg
FUEL CAPACITY 5 gallons OR 18.9 L

Tyres specs

FRONT 140/75R17 67V
REAR 200/55R17 78V
