Yamaha VMax specs
Engine Specs
Type Liquid-Cooled 65-Degree V-4, Dohc, 4 Valves/Cylinder
Displacement 1679 Cm3
Bore X Stroke 3.5X2.6 In Or 89 Mm
Compression Ratio 11.3:1
Horsepower -/- Kw(Hp)/Rpm
Torque 0/- Lb-Ft/Rpm Or 0 Nm/Rpm
Fuel System Fuel Injection With Ycc-T And Ycc-I
Transmission Specs
Gearbox 5 Speed, Manual
Clutch Multiplate Slipper Clutch
Primary Drive –
Final Drive Shaft
Chassis Specs
Frame Aluminium
Front Suspension 52Mm Telescopic Cartridge Fork W/Oxidized Titanium Coating. Fully Adjustable Preload, Compression And Rebound; 4.7 In Travel
Rear Suspension Single Shock W/Remote Reservoir And Remote Adjustable For Preload, Compression And Rebound
Front Brake Dual 320Mm Wave-Type Discs; Radial Mount 6-Piston Calipers, Brembo Radial Pump Master Cylinder
Rear Brake 298Mm Wave-Type Disc, Single-Piston Caliper And Brembo Master Cylinder
Dimension Specs
Overall Length 94.3 In Or 2395 Mm
Overall Width 32.3 In Or 820 Mm
Seat Height 30.5 In Or 775 Mm
Weelbase 66.9 In Or 1699 Mm
Ground Clearance –
Weight 683 Lbs Or 310 Kg
Fuel Capacity 4 Gallons Or 15.1 L
Tyres Specs
Front Bridgestone Radial 120/70-R18 59V
Rear Bridgestone Radial 200/50-R18 76V
